Placa base msi intel h310m pro – vdh plus socket 1151 ddr4 x2 2666mhz max 32gb d – sub dvi – d hdmi

Processor
supports 8th generatión intel® core processors – pentium® gold and celeron®
processors for socket lga1151
see supported processors
chipset1
this chipset is me11 firmware based and doesn’t feature sda3.0.
intel® h310 chipset
this chipset is me11 firmware based and doesnt feature sda3.0.
memory
2 x ddr4 memory slots – support up to 32gb
supports ddr4 2666 – 2400 – 2133 mhz (by jedec)1
supports ddr4 2666 – 2400 – 2133 mhz (by xmp oc)1
supports dual – channel mode
supports non – ecc – un – buffered memory
supports intel® extreme memory profile (xmp)
2666 mhz for i7 and i5 processors only.
see supported memory
slots
1 x pcie 3.0 x16 slot
2 x pcie 2.0 x1 slots
onboard graphics
1 x vga port – supports a maximum resolutión of 2048×1536@50hz –
2048×1280@60hz – 1920×1200@60hz
1 x dvi – d port – supports a maximum resolutión of 1920×1200@60hz
1 x hdmi port – supports a maximum resolutión of 4096×2160@30h
supports up to 2 displays simultaneously.
storage
intel® h310 chipset
4 x sata 6gb – s ports
supports intel® rapid storage technology
usb
intel® h310 chipset
4 x usb 3.1 gen1 (superspeed usb) ports (2 type – a ports on the back panel – 2
ports available through the internal usb connector)
6 x usb 2.0 (high – speed usb) ports (4 ports on the back panel – 2 ports available
through the internal usb connector)
audio
realtek® alc887 codec
7.1 – channel high definitión audio
lan
1 x rtl8111h gigabit lan controller
internal connectors
1 x 24 – pin atx main power connector
1 x 8 – pin atx 12v power connector
4 x sata 6gb – s connectors
1 x usb 3.1 gen1 connector (supports additiónal 2 usb 3.1 gen1 ports)
1 x usb 2.0 connector (supports additiónal 2 usb 2.0 ports)
1 x clear cmos jumper
2 x front panel connectors
1 x seríal port connector
1 x tpm module connector
1 x chassis intrusión connector
1 x front panel audio connector
1 x 4 – pin cpu fan connector
1 x 4 – pin system fan connector
dimensións
8.9 in. x 7.3 in. (22.6 cm x 18.5 cm)
m – atx form factor
